Stress analysis

The structural analysis is carried out both on metallic products and on composite materials.
In particular, besides the usual resistance deformation and structural instability tests, failure analysis on carbon laminates and fracture modes associated with such components are carried out.

Static linear and non-linear analysis are the main calculation
techniques employed.

M346 skins analysis
M346 frame & duct analysis


Calculation to evaluate (front impact
at 54 kmph)the structure of the split
rear seats with seatbelts on board
project 223 (doblÚ)
(use of RADIOSS software)

Calculation to evaluate the structure of the split rear seats






Evaluation by means of static calculation of the structure
of the front seats (use of I-DEAS software).

Evaluation by means of static calculation of the structure of the front seats
